What is a built up roofing system

ARMA defines a built-up roofing system as a roof where multiple layers of asphalt alternated with ply sheets (felts) are applied over the roof deck (vapor retarder) and, most often over insulation that is attached to the roof decking.

Is built up roofing good?

Built-up roofs tend to provide excellent waterproofing and ultra-violet protection. Thanks to the aggregate top layer, they are also fire-resistant. Built-up roofing is generally low-maintenance and therefore costs little to maintain over its life.

How many layers does a built up roof have?

Built-up roofing systems are most commonly applied with three or four layers of roofing materials to make up the complete roofing system. These layers are typically a base sheet, a fiber sheet, and then either one or two layers of bitumen.

How do you install built up roofing?

First, contractors attach base sheets to the roof’s subsystem using roofing nails. Then, they use tar, concrete, adhesive, or asphalt to glue down felt over the top of the base sheeting. Next, roofers install a layer of gravel or cap sheets, which they then cover with a final layer of asphalt.

What is the difference between built up roofing and modified bitumen?

Modified Bitumen (MB) roofing is an asphalt-based, close cousin of the Built-up-Roof (BUR) designed for buildings with low-slope or “flat” roof structures. … Modified Bitumen roofs give designers and installers an even broader array of options than BUR.

How much does a built up roof cost?

The average roofing installation price for a tar and gravel (built up) roof costs anywhere between $3,750 to $6,750 depending on the slope, pitch, and size of your roof. You can expect to pay $2.50 to $4.00 per sq. foot or $250 to $400 per square installed on a standard sized single story home.

How long does a built up roof last?

If properly installed and maintained, a commercial built-up roof can last 40 years. There are a few other benefits of built-up roofing systems: Seamless and Waterproof – The continuous solid surface does not require joints or seams, removing the most vulnerable area for leaking.

What is 4 ply built up roofing?

A 4-Ply roofing system involves roofing felts that are typically four plies composed of layers of reinforcement such as fiberglass or polyester felts, with each ply being embedded in a full bed of hot asphalt/bitumen.

Is a built up roof Class A?

Built-up Roofing When re-roofing a building that is located within a “FBZ”, “MFD”, or “VHFH” fire district, the portion of the roof covering which is re-roofed shall comply as an approved Class A roof covering.

What is a flat built up roof?

A built-up roof, most of the time referred to as BUR, is a time-tested roofing system typically comprised of hot tar and gravel. It is made up of many layers and typically the top layer is where the tar and gravel lie. … Of all the flat roof options available today, BUR has been around the longest.

Article first time published on

How much does built up roofing weight?

The weight of a built-up roofing system can range from about 2.5 pounds per square foot for a smooth surface to 6.5 pounds per square foot for a gravel surface. Though not nearly as heavy as a slate roof or a clay tile roof, built-up roofing is generally heavier than asphalt shingles, TPO, PVC, and metal roofs.

What is a 3 ply built up roof?

A 3-Ply Hybrid BUR differs from other membrane options due to its combination of a 1ply base sheet with two plies of glass felt that enhances the performance of the membrane with a quicker installation time and less weight on the roofing system itself.

What is a membrane roofing system?

Membrane roofing is a type of roofing system for buildings, RV’s, Ponds and in some cases tanks. It is used to create a watertight covering to protect the interior of a building. Membrane roofs are most commonly made from synthetic rubber, thermoplastic (PVC or similar material), or modified bitumen.

Is TPO better than tar and gravel?

We most certainly advise customer to use TPO instead of a Tar & Gravel roof based on what we’ve mentioned above. It’s cheaper, more environmentally friendly and, generally, easier to repair should something happen.

Is TPO better than modified bitumen?

Unless you are on an extremely restricted budget and need the cheaper roofing material right now, TPO is a superior choice. When it comes to which is the better material, TPO wins on most points. Despite that, modified bitumen is still around, and there are still roofers who are happy to work with it.

How long does a bitumen roof last?

Modified bitumen roofing is a long-lasting material with an average life span of 20 years. But since it’s a low-maintenance roofing system, it can last even longer with just basic care and maintenance.

What is the difference between built-up roofing and single ply roofing?

Built-up systems are installed by alternating layers of asphalt or tar and supporting fabrics directly onto the roof. You can choose the number of layers (or plies) that are installed. … Single-Ply Membrane Roofing Systems have been the go-to roofing for commercial, industrial, and manufacturing facilities for decades.

What is the best type of flat roof?

EPDM Membranes Quite possibly the best flat roofing membrane, EPDM is a relatively low-cost flat roof material that offers a number of significant advantages. Clean, straightforward installation, incredible strength, a long lifespan, and a smart finish combine to make EPDM membranes a difficult one to beat.

What is the purpose of gravel on a built-up roof?

Gravel is added on top of tar (and sometimes Single-Ply EPDM) roof systems as protection from UV rays, foot traffic, and wear from weather. If the gravel stones break down, they become less effective and leave your important roof layers prone to wear and damage.

What is the average life expectancy of a tar and gravel roof?

How Long Does A Tar And Gravel Roof Last? A tar and gravel roof will last, on average, anywhere from 20-years to 25-years. That is a fairly standard lifespan for a roof – asphalt roofs, for example, last around 20 years.

Can you put a metal roof over tar and gravel?

You’ll be able to save up to 25% in labor costs by not tearing off your old asphalt roof, installing new underlayment, or the fees to dump the old roofing materials. So, yes, you can install a metal roof over your old asphalt roof.

How thick is a built-up roof?

How thick is built-up roofing? A BUR roof system comes in multiple layers, most often between two and four. The thickness depends on the materials used and the number of built-up roofing layers applied, but typically the selvage area ranges between two to four inches.

What is PVC roofing?

PVC is a high quality, durable option for commercial roofs. … Made from polyvinyl chloride (or in layman’s terms, plastic), PVC is a great single-ply roofing solution. It’s made from a lower percentage of oil and petroleum than thermoplastic polyolefin (TPO) or ethylene propylene diene terpolymer (EPDM).

Can you walk on EPDM?

Yes to an extent. EPDM is designed to take LIGHT foot traffic during installation and for occasional cleaning or maintenance. If you require more use than this, i.e. for a balcony then there are additional materials that can be laid over your EPDM for a more durable solution.

Can you walk on a flat roof?

In general, all types of roofs aren’t safe to walk on, especially if you don’t have the necessary training. … A commercial flat roof can be used for recreational purposes or to create extra storage space, but it must be constructed to withstand the foot traffic and the extra weight of any equipment you bring up.

Why are flat roofs so expensive?

Greater Chance of Leaks — Again, the problem with flat roofs is that they’re flat. Even though most are designed with a slight slope, they’re not great at shedding a lot of rain or snow. … For this reason, flat roofs tend to cost more overall than pitched roofs.

What is built up bituminous waterproofing?

Bituminous waterproofing systems are designed to protect residential and commercial buildings. Bitumen (asphalt or coal-tar pitch) is a mixed substance made up of organic liquids that are highly sticky, viscous, and waterproof.

What is EPDM roof membrane?

EPDM is an extremely durable synthetic rubber roofing membrane that is used worldwide. … Its superior durability and cost-effectiveness are part of what makes EPDM one of the most popular flat roof systems installed in the U.S. today.

What is a hybrid roofing system?

The Hybrid System is a multi-layered, high-performance roofing solution using superior, time-proven materials. It utilizes not one but two roofing systems to produce one of the strongest, longest lasting roofing systems in the industry.

What is the minimum pitch for a EPDM roof?

Be positive that the roof has at least a 1 to 80 fall. This is the absolute minimum for and EPDM rubber roof (also good practice for any flat roof in general) to prevent ponding.

What is a 2 ply roof?

Commercial Roof USA specializes in a 2 ply rubber roofing system which is the Modified Bitumen Torch Down membrane. The 2 ply system consists of a fiber base sheet with a self adhering modified base attached to it, which is considered the first layer.
