How tight do you tighten serpentine belt

A general rule of thumb for the correct tightness is being able to twist a belt with a thumb and finger a 1/2 turn and feel resistance. If you can turn it more than a 1/2 turn, you do not have enough tension on the belt. If you cannot turn it a 1/2 turn, you have too much tension on the belt.

How tight should the belt tensioner be?

A general rule of thumb for the correct tightness is being able to twist a belt with a thumb and finger a 1/2 turn and feel resistance. If you can turn it more than a 1/2 turn, you do not have enough tension on the belt. If you cannot turn it a 1/2 turn, you have too much tension on the belt.

What is the belt tension?

The tension belt is a pulley-mounted system that is loaded on a spring or pivot point mechanism. … The belt tension must have the proper amount of tension to keep the Accessory Belt Drive System from failing. The belt system transfers torque to run the accessories.

Can you tighten a serpentine belt too much?

An over-tightened belt can burn out any bearing that the belt rotates on, including alternator, power steering pump, A/C compressor, idler pulleys, etc. An over-tightened timing belt can ruin any pulley bearing it is connected with.

Can you tighten a tensioner?

Turn the adjustment bolt on the side, top or bottom of the pulley counterclockwise with the ratchet and socket until the accessory belt is loose enough to remove. Tighten the tensioner pulley by turning the adjustment bolt clockwise with the ratchet and socket until the belt is tight.

Why does my serpentine belt not fit?

Serpentine belt problems usually result from one of three causes: a defective belt tensioner; misalignment of a pulley; or, defective bearings in the tensioner, idler, or one of accessories driven by the belt (including the water pump). … Frayed belt edge: Misalignment of an accessory drive pulley.

How much play should be in a serpentine belt?

Check the tension of the belt periodically. To do this, grab any area of the belt that is between two pulleys with your fingers. There should be approximately 1/4 inch play in the belt for most vehicles.

How do you know if your serpentine belt is slipping?

The symptoms of a loose serpentine belt include a loud squealing noise when the engine is started or when the steering is turned all the way to one side. A serpentine belt that keeps slipping off the pulley is another symptom of a bad tensioner. The solution is to replace a serpentine belt and a belt tensioner.

Can a tight serpentine belt cause loss of power?

A. If the belts are too tight, they can put a strain on the shaft (and its bearing) of the alternator, power-steering pump and even the water pump. Most belts are installed on the tight side because they take an initial stretch. … It looks like the power-steering fluid level is getting low.

What causes pulley misalignment?

Angular Misalignment This occurs when pulleys become “tilted” because their shafts are not parallel. Worn bushings and bearings can allow rotating shafts to become cockeyed in their bores. Premature bearing and bushing wear is often caused by the strain of excessive belt tension.

Article first time published on

What is the most common cause of belt slippage?

Improper belt tension is the most common and obvious cause of slip, which generates unwanted heat. The friction that occurs when a V-belt slips in a pulley causes belt sidewalls to become glazed, and decreases gripping ability.

What happens if serpentine belt is loose?

If there is not enough tension, a belt can slip, squeal or run hot. … Quick fact: If your serpentine belt is loose, you may have other mechanical problems like under-performing water pump, which can cause the engine to overheat. Avoid performance loss.

What are the symptoms of a bad tensioner pulley?

If the tensioner is loose the belts may squeak or squeal, especially when the engine is first started. It is also possible for the tensioner pulley or bearing to wear out, in which case the vehicle will produce a grinding noise from the pulley.

What does a misaligned serpentine belt sound like?

Noises that indicate your drive belt may be misaligned A chirp is a repetitive, high-pitched noise that doesn’t last long, and is usually worse when the engine is idling. … A squeal, on the other hand, is a chirp that gets louder and increases in volume along with engine speed.

What happens if pulleys are not aligned?

When pulleys are not aligned properly, additional loads are induced. The aim of belt alignment is to align the grooves of the drive and driven pulleys so that the belts run with minimal wear. Proper alignment extends the service life of belts and bearings, reduces vibration and noise levels, and saves energy.

Can you stretch serpentine belt?

But stretching the belt with the right tools is often the only way stretch belts can be installed. Stretch belts can take loads off of the main accessory belt drive, allow for better packaging and solve NVH problems that can occur with a longer serpentine belt.

Can a bad serpentine belt cause rough idle?

Poor Driving Experience So if you have searched for answers to the question, can a bad serpentine belt cause rough idle? The answer is yes.
