How many sprinklers can you put on one station?
How many sprinklers can you put on one station?
At different pressures, the sprinkler head and nozzle will consume different amounts of water. For example, at 35 pounds per square inch (PSI) the 5000 Series Rotor using the 3.0 nozzle will use 3.11 gallons per minute (GPM). If your home’s water capacity was 10 GPM, you could place 3 heads per zone.
Do you need a valve for each sprinkler zone?
An irrigation system is typically divided into several zones, each of which feeds sprinkler heads in a different area of the lawn or garden, and each zone is controlled by a valve that receives signals from a centrally located controller. In this case, it’s usually quite easy to find the valves.
How does a station work on a sprinkler system?
A station is a circuit on the controller that activates a single control valve. Each valve controls a specific group of sprinklers, sometimes referred to as a watering station.
What does a zone mean on a sprinkler system?
Each valve controls a specific group of sprinklers, sometimes referred to as a watering station. A zone is the actual area that is receiving water, although on the controller it is called a “station”. It is a section of the irrigation system monitored by a single control valve.
How to set the orbit sprinkler station time?
1 Choose the watering duration for the stations by sliding each switch to its desired time from 2 to 120 minutes. 2 To skip a station, move the station’s slide switch to the MANUAL OFF position at the bottom of the slide. 3 Set the program slide switch for each station that you want to assign to program A or B, or A and B.
Where is the valve box on a sprinkler system?
The valve box is generally a green box located somewhere on the lawn. Inside the valve box there is generally 1-4 valves as pictured below. If you can’t find the valve box call us:
Why are sprinkler systems broken down into stations?
Because of water pressure and layout, most sprinkler systems are broken down into stations. Not only does this help with efficiency, but it can help narrow down what part of your system is causing sprinkler problems.
1 Choose the watering duration for the stations by sliding each switch to its desired time from 2 to 120 minutes. 2 To skip a station, move the station’s slide switch to the MANUAL OFF position at the bottom of the slide. 3 Set the program slide switch for each station that you want to assign to program A or B, or A and B.
How do you turn on a sprinkler system?
You’re actually manually turning on the zone by twisting the solenoid open. If, by manually turning on the zone your sprinkler heads pop up and start the irrigation, you have successfully verified that there is water pressure to the whole system and can check that off of your list as a potential cause for the problem.
Why does my sprinkler system have less pressure in one zone?
One of the zones functioning might get less pressure than the other one. Make sure that the zones of your sprinkler system are working one at a time to make sure there is no splitting of water pressure that allocated for one valve. Turning off one of the zones that are working, will correct your problem in no time.
