How far from the soil stack can a toilet be

Install the new toilet within six feet of the main soil stack in your house, if possible. The main stack is a length of 3- or 4-inch pipe that runs vertically from the main bathroom to the sewer. The diameter of the stack above the main bathroom reduces to 2 or 3 inches and extends through the roof.

How far can you run a toilet waste pipe horizontally?

The toilet can be as far as 10 feet from the stack if the waste line is 4 inches in diameter.

How far can a toilet be moved?

However, you can also move the toilet to a certain extent without having to change the waste line and stack. If your waste line has a diameter of 3 inches, you can place the toilet within six feet of your stack. The toilet can also be as far as 10 feet from your stack, if the diameter of the waste line is 4 inches.

How much clearance do you need next to a toilet?

Most codes require at least 15 inches (measured from the center of the toilet) from any side wall or obstruction and not closer than 30 inches center to center to any other sanitary fixture. (The NKBA actually recommends 32 inches.) There should be at least 24 inches of clear space in front of a toilet or bidet.

How far can a toilet be from waste pipe?

Also if you run long, horizontal pipes from your toilet will the waste get stuck part way? The furthest the toilet would be away from the pipe is 2metres due to the size of the bathroom.

How far should a toilet be from the back wall?

The Distance To Set The Toilet Flange From The Back Wall. You’ll want to set the center of the water closet flange 12 inches from the finished back wall.

How far can a soil pipe run horizontal?

longest run for horizontal soil is 6 metres, but what about when u add bends.

How wide should a toilet space be?

When designing the area your toilet will sit, you must provide a floor space that is at least 30 inches wide and 60 inches long. A minimum spacing between the center of adjacent fixtures of 30 inches.

How much space do you need around a toilet UK?

Minimum sanitaryware sizes The toilet and bidets must have a minimum space of 70cm in width and 120cm in length. If they are next to a wall, the minimum free space should be 20cm, and if there is an element on their side, they should not be placed less than 15cm away for greater usability.

Can you move toilet location?

Moving the toilet is not a change to be taken lightly. But if needed, it can be accomplished with substantial plumbing work and a great deal of peripheral work, such as opening up a floor or ceiling, rerouting pipes and drain flange, and re-installing the toilet and other fixtures.

Article first time published on

Can a toilet waste pipe be moved?

There is usually a vertical waste water pipe under the toilet that uses gravity to move wastewater away. For the waste water line, an offset toilet flange will allow you to move the toilet a couple of inches in any direction without having to cut a new hole in the floor or reconstruct the waste water pipe.

Is it expensive to relocate a toilet?

The cost to move a toilet or sinks can be $2,500-$3,500 per fixture. Plumbing can be a significant cost factor in a remodel when a bathroom floor plan is altered. The toilet is the most expensive to move. Connecting the toilet to the existing sewer line can be a bit tricky for your plumber.

How many bends can a soil pipe have?

Bends. Bends at the base of stacks should be of long radius. Two 45° bends may be used as an alternative.

How far can a drain be from the stack?

There is a vent between the sink P-trap and the point where the waste line goes to the main sewer. The vent can’t be more than 2 1/2 feet from the trap if the waste line has a diameter of 1 1/2 inches. The critical distance is 3 1/2 feet if the waste line is 1 1/2 inches.

How far is toilet pipe from wall?

The standard distance from the back wall is 12 inches, or 12-1/2 inches from the center of the flange to the wall framing. Minimum distance in front of the toilet to the facing wall or fixture is 21 inches.

Can a toilet drain run horizontal?

Only 3 total water closets are permitted to discharge into any 3 inch horizontal drain in the UPC. The IPC does not have this limitation. It’s 4 inches on the inlet of the fitting and 3 inches on the outlet. The plumbing code never allows a drain to be reduced in size in the direction of flow.

How long can a waste pipe be?

The limits can be very restrictive and are as little as 1.7m for a 32mm waste pipe to a wash hand basin. By increasing the size of the pipe, you can place the fitting further away – typically between 3 and 4m away for a 50mm pipe.

What is a toilet waste stack?

A waste stack is a vital component in your home’s plumbing system. Also known as a drain-waste-vent (DWV) system, the waste stack is a large-diameter pipe that receives water from toilets and other drains and runs all the way through the house vertically.

How far should a soil pipe be from the wall?

Generally, this distance tends to be around 300mm in a cavity wall, so take this measurement and add an extra 300mm onto this figure – this will allow the WC waste connector to be fitted.

What is the depth of a toilet?

Overall, a standard toilet will be between 27 and 30 inches deep, with a back height of 21 to 31 inches and a width of about 20 inches. An ADA-compliant version needs to have a seat height of 17 to 19 inches. This is one reason why partitions around ADA-compliant bathrooms are different.

Why is my new toilet so far from the wall?

When toilet flanges are installed it is typically in the early stages of the project and the standard 12” measurement is taken from the drywall, rather than the finished tile surface that you are measuring from. That means your flange was set at a distance further from the wall than even the 13″ you measured.

How close can a toilet be to a wall UK?

If the toilet is situated on a branch drain, it cannot be upstream from the sink or shower. The minimum side distance allowed from the centre of the toilet bowl to a wall is 15 inches 12 inches to a bathtub, and clearance from the front of a bowl to a wall or fixture should be 21 inches.

Do you need planning permission to build a downstairs toilet?

Usually, adding a downstairs toilet to your home does not require planning permission, unless it is part of a larger extension. … Speak to your planning consultants and they can advise you on where you stand with planning permissions. Your new toilet will have to adhere to building regulations.

Is 60cm wide enough for a toilet?

Whatever sink you choose, you should allow at least 60cm between the front of the sink and the wall or any other fitting opposite for passage. A toilet hung from the wall, and with a concealed cistern, brings a sense of space to any bathroom.

Why is the toilet always next to the shower?

Toilets tend to be next to bathtubs because both of them tend to be in a small room that is kept rather private from the rest of the house and because both of them need to have fairly substantial plumbing in order to operate correctly.

How close can a toilet be to a bathtub?

It is recommended that the distance from the centerline of a toilet and/or bidet to any bath fixture, wall, or other obstacle should be at least 18 inches. The minimum distance from the centerline of a toilet and/or bidet to any bath fixture, wall, or other obstacle is 15 inches.

How much room do you need for a toilet and sink?

Each has a minimum space allowance to pass code. A toilet requires a minimum 30 inches of space to sit in by itself: 15 inches from the center line out to each side. Sinks require a minimum of 20 inches of space to sit in, if they are the only sink in the room.

Is it possible to move a toilet in a bathroom?

Moving a toilet is not a straightforward weekend DIY job, but it is very doable when you involve the professionals. Once the toilet itself is removed, your plumber will have to move the drainage, as well as the water supply to accommodate the new location.

Can you replace a 10 inch rough in toilet with a 12 inch rough in toilet?

The rough-in for your bathroom plumbing should match the rough-in for the toilet. Even if a toilet is designed for a 10-inch rough-in, you can still install it in a space with a 12-inch rough-in.

Can you switch a toilet and shower?

It’s not – well, they’re going to drain to the same place but you would have to reconfigure the plumbing. So it’s not quite that easy to swap toilet, shower locations but not impossible. … Because switching those is a big job; you’re going to have to tear up the floor to do the plumbing.

Can you extend a soil pipe?

Depends how far you’re moving it, and whether it’s currently horizontal or vertical. If it’s vertical it shouldn’t be a problem. You’ll need a pan connector, a run of horizontal (with a fall) soil pipe, and a 90 deg bend. Fit it, box it in.
