How does the k-8304-k-Kohler shower cartridge work?

Single lever design cycles from off through cold to hot. Provides temperature regulation and automatic anti-scald protection. One piece cartridge design simplifies installation and maintenance. Adjustable high temperature limit stop to control maximum water temperature.

Which is pressure balancing valve does Kohler use?

The Rite-Temp valve platform uses the latest pressure-balancing technology to provide anti-scald protection and temperature control for enhanced showering comfort. Once the valve is installed, select your finished trim and finish from KOHLER’s comprehensive design portfolio.

What kind of shower valve does Kohler use?

Cartridge features square metal stem. Cartridge held in place by a bonnet. Sculpted acrylic handle lifts up, then rotates left to right to adjust temperature. Came as a pressure balanced and non-pressure balanced option. Valve cartridge GP30413 may resolve leaking from the showerhead or spout.

Is the k-8304-k pressure balancing valve body and cartridge?

Rough-in guide designed for both standard and thin wall installations. Installed valve rough-in can be flushed and pressure tested to 150 psi max (air or water) without cartridge using included K-10351 test cap. 4.4 out of 5 stars. Read reviews for pressure-balancing valve body and cartridge kit

What kind of PBU does a Kohler shower valve have?

The valve had a PBU with smooth o-rings. The K-2971 has a PBU with notched o-rings. The PBU GP1144925 is interchangeable and used with both the K-306 and K-2971. Black mixer cap has 2 screws located at 3 and 9 o’clock that screw the cap to the brass valve body. The square brass stem rotates clockwise to turn on. Manufactured from 1997-2004.

Can you change the valve on a Kohler shower?

Once the valve is installed, select your finished trim and finish from KOHLER’s comprehensive design portfolio. Should you decide to remodel in the future, simply change out your trim for the latest design without the need to change the valve installation. Includes valve body, pressure balance cartridge, rough-in guide, and mudguard.

What do you need to know about Kohler rite temp?

The new KOHLER Rite-Temp valve system sets new standards for ease of installation, application versatility, and long-term reliability, simplifying your plumbing project and providing maximum flexibility for future changes or upgrades.

When did Kohler replace the k-305 shower valve?

The K-305 valve was discontinued June 2010 and replaced by the K-11748 valve. Excessive inlet pressure can also contribute to a leak or drip issue. If suspected, turn the pressure by adjusting the stops or installing a pressure reducing valve in the supply system.

What should the water temp be in a Kohler shower?

NOTE: The water temperature should never be set above 120 degrees F. Remove the handle and trim from the wall to expose the cap assembly (Fig. 1). Remove the black o-ring, caution tag, and red collar from the round brass stem; older model will have a black collar (Fig. 2).
