How does a Kohler shower control valve work?

The brass, round, splined stem rotates clockwise to turn on. Push or push/pull diverter diverts water from the bottom port outlet to the top port outlet. Note: The K-305 Rite-Temp Diverter Valve features a smooth diverter stem. The K-11748 features a threaded diverter stem. Reference the photo below for more detail.

Can a three ribbed shower valve be replaced?

Three-ribbed brass cap can be replaced with plastic mixer cap GP77759. Writing on the trim may not match and depth of the valve must be considered to ensure trim is flush with finished wall. Complete conversion kit, including mixer cap and PBU, GP876851, may work for three-ribbed valve.

What kind of pressure balancing unit does Kohler shower use?

Valve cartridge GP30413 may resolve leaking from the showerhead or spout. Pressure Balancing Unit (PBU), if included, GP800820 may resolve temperature issues.

Where is the Black mixer Cap on a Kohler shower?

Cartridge (GP800881) may resolve leaking from showerhead/spout or temperature issues. K-8304-K-NA Service Parts information. Black mixer cap has 2 screws located at 3 and 9 o’clock that screw the cap to the brass valve body.

Where is the temperature limit stop on a Kohler shower?

Features an orange temperature limit stop attached to stem of the mixer cap. The brass, round, splined stem rotates clockwise to turn on. Cartridge (GP800881) may resolve leaking from showerhead/spout or temperature issues. K-8304-K-NA Service Parts information.

How to identify single control Bath and shower valves?

Identify a Single Control Bath/Shower Valve Finding a KOHLER or STERLING Product Model Number or Serial Number Rite-Temp K-304 Service Part Installation Instructions Identifying and Removing Single-Control Bath and Shower Valve Trim Identifying Your Faucet Model TOP Kohler.com homeSign up for NewsletterFind a storeLegalPrivacyCookie Policy

Where is the mixer Cap on a Kohler shower valve?

Another resource to help you identify your bath/shower valve is this interactive flow chart that will guide you through the identification process. Black mixer cap has 2 screws located at 3 and 9 o’clock that screw the cap to the brass valve body. Features a red or black temperature limit stop attached to stem of the mixer cap.

How to adjust the hot water on a Kohler shower valve?

How do you adjust the hot water on a Kohler shower valve? Remove the handle. You may need a screwdriver to do this. Take off the metal cover beneath the handle, exposing the valve stem. Turn the RSL two notches in whichever direction desired, then put the RSL back in place. Replace the faucet

What do you need to know about Kohler shower?

Kohler’s most advanced digital showering system with a touch-screen interface, DTV+ gives you the ability to control water, light, sound and steam for a true multi sensory showering experience. Learn more about DTV+. Learn about Shower Valves.

How to identify single control Bath and shower valve?

This allows you to expose the valve for proper identification. For assistance with removing the trim, refer to “Identify and Remove Single-Control Bath and Shower Trim”. Once the trim is removed, refer to the information below to identify your shower valve.

What to do if your Kohler shower valve is leaking?

Kohler shower valves occasionally require service. The first step in correcting a dripping or leaking valve is to identify the valve installed in your home. Assistance identifying the valve can be found in the “Identify a Single Control Bath/Shower Valve” article.
