How do you program a Toro sprinkler timer?
How do you program a Toro sprinkler timer?
How to Set the Timer for Toro Sprinkler Systems
- Turn the program dial to the “Auto/On” setting.
- Slide the program switch to the zone you wish to program.
- Turn the Toro Sprinkler timer dial to the “Set Time/Day” position.
- Turn the dial to the “Set Watering Days” position.
Where can I find the Toro ECX user manual?
ECx Introduction and Set Up Timer Components PGM A B C AUTO / ON SU MO TU WE TH FR SA RAIN SET TIME / DAY DELAY MANUAL NEXT START WATERING DAYS SEASON PROGRAM ADJUST START SET ZONE TIMES PROGRAMS… Page 5 Timer Components 2 – Control Buttons The following are brief descriptions of the ECx compo- nents and display elements.
What are the features of the ECX sprinkler system?
Page 1 User’s Guide Automatic Sprinkler System Timer ECx Features: • Expandable Up To 8 Zones With Plug-In Modules • 3 Watering Programs With: AUTO / ON – Calendar and Interval Days RAIN SET TIME / DAY DELAY – 1 Min. to 4 Hrs. Zone Run Time…
What kind of wire do you need for Toro irrigation?
1. Route the valve control wires between the valves and the timer. Note:The snap-in wire connectors accept 14 to 18 gauge wire. Using 18-gauge, multi-strand, direct-burial irrigation cable is recommended. Choose a cable that has at least one more wire conductor than the number of valves to be connected. 2.
Can a Toro pump be connected to a rain sensor?
Do not connect the timer directly to the pump starter. Connecting A Toro Rain Switch (Optional) The Toro Rain Switch (model # 53221) is a remote rain SENSOR FUSE sensing device which can be connected directly to your 9V Battery ECx to automatically interrupt watering during rain. NiCad DELAY 24HR… Automatic PROGRAMS Mode.
What do you need to know about Toro sprinkler controllers?
Irrigation Timers, Sprinkler Timers, Irrigation Controllers | Toro Irrigation timers and controllers are the brain of your system, telling your sprinklers what day, what time and exactly how much to water. Toro sprinkler timers are as easy to program as an alarm clock. Home Products
